No. |
Test item |
Standard request |
Testing result |
|
| 1 |
Status in container |
After stirring, there are no hard lumps and it is in a uniform state |
After stirring, there are no hard lumps and it is in a uniform state |
|
| 2 |
Construction capability |
Apply two coats of barrier free paint |
Apply two coats of barrier free paint |
|
|
3 |
Vertical combustion performance |
V-0 grade |
Pass |
|
|
4 |
Covering power, g/m2 |
≤150 |
110 |
|
|
5 |
Drying time, h |
Surface drying time |
≤4 |
Pass |
|
Full drying time |
≤24 |
Pass |
||
|
6 |
Fineness, μm |
≤60 |
60 |
|
|
7 |
Water resistance, 168 h |
No abnormalities |
168h No abnormalities |
|
|
8 |
Acid resistance, 5%H2SO4, 96 h |
No abnormalities |
96h No abnormalities |
|
|
9 |
Salt water resistance, 3%NaCL, 120h |
No abnormalities |
120h No abnormalities |
|
|
10 |
Salt spray resistance, 500 h |
No foaming, no shedding |
2500h No abnormalities |
|
|
11 |
Adhesion, Grade |
≤1 |
0 |
|
|
12 |
Bending resistance, mm |
≤2 |
2 |
|
|
13 |
Impact resistance, cm |
≥30 |
50 |
|
|
14 |
Coating temperature change, 5 cycles |
No abnormalities |
No abnormalities | |
|
15 |
Corrosion resistance |
Crusted, grade |
≥8 |
8 |
|
Settleability,grade |
≥6 |
8 |
||
|
16 |
Resistance to artificial aging, 500 h |
No foaming, no peeling, no crack pulverization ≤1 grade; Discoloration ≤ grade 2 |
1000h No bubbles, no peeling, no cracks Pulverized 0 grade; Color change 1 grade |
|
|
17 |
Breakdown strength |
≥10kV |
15.3 | |
The requirements for coating thickness for anti-corrosion vary depending on the corrosive environment in which the steel structure is located (the following atmospheric environment classification is classified according to ISO 9223-2012):
For atmospheric environments of C1 and C2 levels, it is recommended that the coating thickness be greater than 0.1mm;
For C3 level atmospheric environments, it is recommended that the coating thickness be greater than 0.15mm;
For C4 and C5 atmospheric environments, it is recommended that the coating thickness be greater than 0.2mm;
For CX grade atmospheric environments, it is recommended that the coating thickness be greater than 0.3mm.
Estimated usage table
|
Film thickness (μm) |
Dosage per square meter (kg) |
Coating area per kilogram (m2) |
|
100 |
0.23 |
4.32 |
|
150 |
0.35 |
2.88 |
|
200 |
0.46 |
2.16 |
|
250 |
0.58 |
1.73 |
|
300 |
0.70 |
1.44 |
|
350 |
0.81 |
1.23 |
|
400 |
0.93 |
1.08 |
|
Note: The actual amount of coating will vary depending on the substrate, surface roughness, construction method and technology, and the amount of loss at the site. |
||
Surface treatment
|
Base material |
Minimum |
Recommended |
|
Carbon steel |
Sa2 |
Sa2 |
|
Painted surface |
Clean, dry and intact compatible primer |
Clean, dry and intact compatible primer |
|
stainless steel |
The surface needs to be manually or mechanically polished with non-metallic abrasives, fibers, or hand sandpaper to form a rough surface, ensuring no smooth surface |
Use approved non-metallic abrasives for sandblasting cleaning to produce a sharp and angular rough surface |
|
Galvanized steel |
The surface should be clean, dry, and have a suitable roughness |
Clean the sand with non-metallic abrasives to obtain a clean, rough, and uniform surface |
|
Concrete |
Dry abrasive spray cleaning |
Dry abrasive spray cleaning |
The construction environment should have a temperature greater than 5 ℃, humidity less than 80%, no dust, and it is prohibited to work in rainy or snowy days.
This product can be applied and sprayed in the following way: using airless spraying.
Brush coating: Recommended for pre-coating and small area painting or repair.
Roller coating: recommended for pre-coating and small to medium area coating or repair.
|
Substrate temperature |
10℃ |
15℃ |
23℃ |
30℃ |
40℃ |
|
Surface （touch）drying time |
6 hours |
4 hours |
2 hours |
1 hour |
30 minutes |
|
Reapply after drying, minimum interval |
8 hours |
6 hours |
3 hours |
2 hours |
1 hour |
|
Dry/cure until ready for use |
48 hours |
36 hours |
24 hours |
18 hours |
12 hours |
The determination of drying and curing time is based on temperature and relative humidity, with relative humidity below 85%. Surface (touch) dryness: a state where there is no residue or adhesion of fingerprints when lightly pressed with fingers.
After drying, reapply with the shortest interval: the recommended shortest time interval for applying the next coating. Drying/curing to usable: The shortest time the coating can be permanently exposed to a specific environment/medium.
